Amana tool RC-2453 CNC Insert Multi Profile Step 3 for MDF Cabinet Doors 32mm D x 24 mm CH x 1/2 SHK

Step 3 Excellent for: MDF & Wood W = width of the frame.H = maximum depth of the frame. The dimension W determines the frame width. The dimension H determines the profile depth. In the example shown W = 50 and H = 13. Any change in the dimensions of the frame width and depth should be done according to the formula that is written on each tool drawing.
